67 Photos
2019 Mitsubishi FB16PNT FL 2425 lb Electric Forklift
Located
North Franklin, CT
North Franklin, CT
Serial number
AFB2500232
AFB2500232
Loading...
ID number
#14259528
In yard
Yes
Features
3 Stage Mast, Full Free Lift, 93 in Lowered Mast Height, 47 in Forks, Side Shift, 36 V, Battery Watering System
General Appearance
Serial Number / VIN
AFB2500232
Paint
Damage
Body Panels
Rear bumper damaged, Rear top plastic cover is missing screws etc
Fenders
No visible damage or missing components
Hand Rails
No visible damage or missing components
Exterior Lights
The only remaining light is the beacon, which is operable
Safety
Travel Alarm
Operational
Horn
Inoperable
Seat Belts
Operational
Safety Lock Out/Stop
Operational
Current Safety Manual
Current Operator/Maintenance Manual
Control Station
Mirrors
Seat/Armrests
Operator seat cushion damaged, Seat back appears bent
Hydraulic Controls
Steering Control
Drivetrain Controls
Gauges
Operational
Hour Meter
0 hrs, Inoperable hour meter Meter shows no hour values, tried every mode listed-No guarantees made as to actual hours/miles/kilometers; the inspection report reflects what can be visually observed.
Limited Function Check
The main components are in place and operational as noted.
Electric System
Battery Condition
A temporary battery was used to check the functionality of the machine.
Cables and Connections
Battery Charger
Awaiting answer on charger status… if one is included, will send pic, and info
Limited Function Check
Battery in truck will NOT hold a charge… overnight charging was attempted
Drivetrain
Drive Motors
Final Drives
Limited Function Check
The drivetrain was operational.
Hydraulics
Pumps (Hydraulics)
Valves
Hydraulic Tank
Hoses (Hydraulics)
Torn outer jacket on side shift hoses
Steering Cylinders
Electric rotational
Free Lift Cylinder
Mast Lift Cylinders
Mast Tilt Cylinders
Side Shift Cylinder
Limited Function Check
The hydraulic system was operational.
Chassis
Mast/Boom Condition
Chain / Tensioners
Carriage Rollers and Guides
Load Back Rest
Side Shift
Forks
Steering Linkage
Frame Condition
Master Cylinder/Brake Control
Park Brake
Stopped the machine while rolling
Limited Function Check - Brakes
The brake system functioned, stopping and holding the machine.
Left Front Tire
Cracks, Chunks missing, Tears
Left Rear Tire
No visible defects
Right Rear Tire
No visible defects
Right Front Tire
Cracks, Chunks missing, Tears
Tire Condition
2 defective tire(s) Both front are poor
Wheel Condition
No visible damage or missing components
