:Misc. Drilling Components For Sale

Drill Bar Gripper Load Capacity 3500 kg

7 3/4 In Jaws

Hydraulic lifting winch BW1500L with rope pressure roller

Hydraulic lifting winch BW1500L with rope pressure roller

Retracted installation length: 338 mm (overall height) Stroke: 130 mm Piston diameter: 55 mm Rod diameter: 28 mm

Type of suspension rope F (rope with steel core) galvanized drawn Nominal rope diameter (mm) DIN EN 13414-1

Installation length retracted: 1246 mm (plate connection valve) Stroke: 900 mm Piston diameter: 140 mm Rod diameter: 125 mm

Opening pressure: 32 bar Opening pressure DBVs: 350 bar Q max: 300 l/min

Buffer module SSE2420-W Stored energy: 2.0 Wh / 7.2 kJ Input voltage (VDC): 23.5 - 32.0 VDC Charging current standard/fast: 2.0 / 4.0 A

set to 160 bar

with special push-in pipe connection + drive flange Perm. maximum pressure: 300 bar Operating pressure: 300 bar

Rotary gearbox for hose reel Includes motor flange • switching brake • torque support • and torque measurement Drive torque T at : 326 Nm

3-stage planetary gearbox in coaxial design with integrated spring-loaded multi-disc brake in accordance with our drawing SAT275/251 dated 14.10.03 (index 0.1).

Electromechanical cylinder concentrated 50 i=4 • i.e. 500N and 70mm/s 750mm stroke with Hall sensor

1960 N/mm² • U/B Key data: Diameter: 36 Type and direction of grain: Cross grain • right sZ

• 2160 N/mm² • U/B Main data: Diameter: 34 Type and direction of impact: Cross impact right sZ

Nominal rope pull on the drum (1st layer) F N: 60000.00 N

ø 20 ; 1960 N/mm² ; Diepa PZ 371 Rope ends: pointed - pointed

Stroke: 3262 mm Piston diameter: 110 mm Rod diameter: 80 mm

Installation length retracted: 1550 mm (eye-eye distance) Stroke: 1100 mm Piston diameter: 160 mm Rod diameter: 90 mm
